Switches and connectors
Shielding gas connection
TIG-torch connector
Welding current connection
Return current connector
Control cable connection, remote controller
Supply cable
Main switch
Mastertig 2500W AC/DC
Shielding gas connection
TIG-torch connector
Welding current connection
Return current connector
Control cable connection, remote controller
Supply cable
Main switch
Mastertig 3500W AC/DC
7
