10 – MASTER MLS™ 1600, MASTERTIG MLS™ 2000 / 0530

3.2.2.3. TIG welding panel MTL – basic functions

4. Selection button for MMA welding

5. Selection button for arc force (MMA) and pedal low/high (TIG welding)

6. Selection button for hot start (MMA) and gas test (TIG welding)

7. Selection for TIG welding, 4T and 2T functions

8. Selection for HF/contact TIG

9. Selection for panel, pedal and remote control

10. Selection for welding parameters

11. Adjustment for welding parameters

12. Pre-gas 0 - 10 s

13. Upslope 0 - 10 s

14. Welding current

15. Downslope 0 - 15 s

16. Post-gas 1 - 30 s

17. Return to welding current button

4. MMA

Select MMA welding by pressing the selection button of MMA welding. The led lights when

MMA is on.

5. Arc force

Press the arc force button and you will see the numerical value corresponding to the dynamics on

the display. You can change the value by turning the pulse potentiometer. If numerical value is

adjusted negative (-1...9), the arc is softened. The amount of spatter decreases when welding at

the upper end of the recommended current range of the electrode. On the positive side (1...9) the

arc is rough. In TIG mode pedal max. and min. current can be selected.

6. Hot start

By pressing hot start button you will see the numerical value corresponding to the hot start pulse on

the display. You can change the value by turning the potentiometer. In TIG mode gas test function

can be selected.
