Kemppi MINARC 120 Operating Instructions

© KEMPPI OY MINARC 120, 150 / 0546 – 9
6. TECHNICAL INFORMATION
The products meet conformity requirements for CE marking.
Minarc 120AU Minarc 150AU
Connection voltage
1 ~ phase 50/60Hz 240 V +10%...-20% 240 V +10%...-20%
Connection capacity 50% ED MMA 110 A/5,5 kVA 35 % ED MMA 140 A/7,5 kVA
50% ED TIG 120 A/3,5 kVA 35 % ED TIG 150 A/5,0 kVA
100 % ED MMA 80 A/3,9 kVA 100 % ED MMA 100 A/5,1 kVA
100 % ED TIG 80 A/2,2 kVA 100 % ED TIG 110 A/3,3 kVA
Mains cable/fuse,
delayed
1,5 mm² S - 3,3 m/10 A 2,5 mm² S - 3,3 m/15 A
Welding current
range
TIG 5 A/10 V...120 A/15 V TIG 5 A/10 V... 150 A/16 V
Metal arc
welding (MMA)
10 A/20,5 V...
110 A/24,4 V
Metal arc welding
(MMA)
10 A/20,5 V...
140 A/25,6 V
Electrodes, diameter Ø 1,5...2,5 mm Ø 1,5...3,25 mm
Welding current
control
stepless stepless
Open circuit voltage
(VRD)
30 V 30 V
Open circuit power <10 W <10 W
Efficiency 80% 80%
Power factor 0,6 (110 A/24,4 V) 0,60 (140A/25,5 V))
Degree of protection IP 23C IP 23C
Temperature class B (130°C)/H (180°C) B (130°C)/H (180°C)
Range of working
temperature
-20...+40°C -20...+40°C
Range of storage
temperature
-40...+60°C -40...+60°C
External
dimensions:
lengt 320 mm lengt 320 mm
width 123 mm width 123 mm
height 265 mm height 265 mm
Weight 4,0 kg without
connection cable
Weight 4,0 kg without
connection cable
4,6 kg with connection
cable
4,6 kg with connection
cable
Norms AS 1674.2 AS 1674.2
AS/NZS 3652 AS/NZS 3652
WTIA Tech note 22 WTIA Tech note 22
IEC 60974-1 IEC 60974-1
IEC 60974-10 IEC 60974-10
EN 50199 EN 50199
