© KEMPPI OY MINARC 150, 151 / 0531 – 9
Minarc 150 Minarc 151
Connection voltage:
1 ~ phase 50/60Hz 230 V ± 15% 110 V ± 15%
Connection capacity:
35 % ED MMA 140 A/7,5 kVA 140 A/7,5 kVA
35 % ED TIG 150 A/5,0 kVA 150 A/5,0 kVA
100 % ED MMA 100 A/5,1 kVA 100 A/5,1 kVA
100 % ED TIG 110 A/3,3 kVA 110 A/3,3 kVA
Mains cable/fuse, delayed 2,5 mm² S - 3,3 m / 16 A 6 mm² S - 2,0 m / 32 A
Welding current range:
TIG 5 A/10 V... 150 A/16 V 5 A/10 V... 150 A/16 V
Metal arc welding (MMA) 10 A/20,5 V...140 A/25,6 V 10 A/20,5 V...110 A/25,6 V
Electrodes, diameter Ø1,5...3,25 mm Ø1,5...3,25 mm
Welding current control stepless stepless
Open-circuit voltage 85V 85V
Open-circuit power <10 W <10 W
Efficiency 80% 80%
Power factor 0,60 (140A/25,5 V) 0,60 (140A/25,5 V)
Degree of protection IP 23C IP 23C
Temperature class B (130°C)/H (180°C) B (130°C)/H (180°C)
Range of working temperature -20...+40°C -20...+40°C
Range of storage temperature -40...+60°C -40...+60°C
Norms IEC 60974-1 IEC 60974-1
IEC 60974-10
EN 50199 EN 50199
External dimensions:
length 320 mm 320 mm
width 123 mm 123 mm
height with handle 265 mm 265 mm
Weight:
weight without connection cable 4,0 kg 4,4 kg
weight with connection cable 4,6 kg 5,2 kg
6. TECHNICAL INFORMATION
The products meet conformity requirements for CE marking..
