Kenwood KRF-V5200D Service Manual

PARTS LIST
Indicates safety critical components.
Ref. No.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
KRF-V5200D
32
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
Ref. No.
Add-
ress
Parts No.
New
Parts
Description
Desti-
nation
Re-
marks
✽
New parts
Parts without
Parts No.
are not supplied.
Les articles non mentionnes dans le
Parts No.
ne sont pas fournis.
Teile ohne
Parts No.
werden nicht geliefert.
Indicates safety critical components.
L:
Scandinavia
K:
USA
P:
Canada
R:
Mexico
C:
China
I:
Malaysia
Y:
PX(Far East,Hawaii)
T:
England
E:
Europe
G:
Germany
V:
China(Shaghai)
Y:
AAFES(Europe)
X:
Australia
Q:
Russia
H:
Korea
M:
Other Areas
E1 J11-0898-05 WIRE CLAMPER X551 L77-2296-15 CRYSTAL RESONATOR (12.288MHZ) X601 L78-0725-05 RESONATOR (8.38MHZ) X761 L77-2002-05 CRYSTAL RESONATOR (4.332MHZ) CP501,502
RK74GB1J103J CHIP-COM 10K J 1/16W
R11,12 RK73GB2A104J CHIP R 100K J 1/10W R13-16 RK73GB2A222J CHIP R 2.2K J 1/10W R17,18 RK73GB2A472J CHIP R 4.7K J 1/10W R19,20 RK73GB2A103J CHIP R 10K J 1/10W R21,22 RK73GB2A331J CHIP R 330 J 1/10W R23,24 RK73GB2A220J CHIP R 22 J 1/10W R31,32 RK73GB2A104J CHIP R 100K J 1/10W R33,34 RK73GB2A332J CHIP R 3.3K J 1/10W R35,36 RK73GB2A222J CHIP R 2.2K J 1/10W R37,38 RK73GB2A562J CHIP R 5.6K J 1/10W R39,40 RK73GB2A272J CHIP R 2.7K J 1/10W R41,42 RK73GB2A331J CHIP R 330 J 1/10W R43,44 RK73GB2A220J CHIP R 22 J 1/10W R51,52 RK73GB2A104J CHIP R 100K J 1/10W R53 RK73GB2A222J CHIP R 2.2K J 1/10W R54 RK73GB2A153J CHIP R 15K J 1/10W R55 RK73GB2A222J CHIP R 2.2K J 1/10W R56 RK73GB2A183J CHIP R 18K J 1/10W R57 RK73GB2A472J CHIP R 4.7K J 1/10W R58 RK73GB2A562J CHIP R 5.6K J 1/10W R59,60 RK73GB2A103J CHIP R 10K J 1/10W R61,62 RK73GB2A331J CHIP R 330 J 1/10W R63,64 RK73GB2A220J CHIP R 22 J 1/10W R91,92 RK73GB2A272J CHIP R 2.7K J 1/10W R93-96 RK73GB2A103J CHIP R 10K J 1/10W R97,98 RK73GB2A331J CHIP R 330 J 1/10W R111 RK73GB2A104J CHIP R 100K J 1/10W R112 RK73GB2A333J CHIP R 33K J 1/10W R113 RK73GB2A102J CHIP R 1.0K J 1/10W R114 RK73GB2A333J CHIP R 33K J 1/10W R115 RK73GB2A162J CHIP R 1.6K J 1/10W R121,122 RK73GB2A472J CHIP R 4.7K J 1/10W R123,124 RK73GB2A562J CHIP R 5.6K J 1/10W R126-128 RK73GB2A101J CHIP R 100 J 1/10W R151-153 RK73GB2A331J CHIP R 330 J 1/10W R161,162 RK73GB2A472J CHIP R 4.7K J 1/10W R171,172 RK73GB2A101J CHIP R 100 J 1/10W R173,174 RK73GB2A103J CHIP R 10K J 1/10W R175,176 RK73GB2A472J CHIP R 4.7K J 1/10W R181,182 RK73GB2A101J CHIP R 100 J 1/10W R183,184 RK73GB2A103J CHIP R 10K J 1/10W R185,186 RK73GB2A472J CHIP R 4.7K J 1/10W R191 RK73GB2A101J CHIP R 100 J 1/10W R193 RK73GB2A103J CHIP R 10K J 1/10W R195 RK73GB2A472J CHIP R 4.7K J 1/10W R201-206 RK73GB2A101J CHIP R 100 J 1/10W R239 RK73GB2A100J CHIP R 10 J 1/10W R301,302 RK73GB2A221J CHIP R 220 J 1/10W R303,304 RK73GB2A224J CHIP R 220K J 1/10W
R305,306 RK73GB2A221J CHIP R 220 J 1/10W R307,308 RK73GB2A224J CHIP R 220K J 1/10W R309 RK73GB2A2R2J CHIP R 2.2 J 1/10W R311,312 RK73GB2A221J CHIP R 220 J 1/10W R313,314 RK73GB2A224J CHIP R 220K J 1/10W R315,316 RK73GB2A221J CHIP R 220 J 1/10W R317,318 RK73GB2A224J CHIP R 220K J 1/10W R319 RK73GB2A2R2J CHIP R 2.2 J 1/10W R321,322 RK73GB2A221J CHIP R 220 J 1/10W R323,324 RK73GB2A224J CHIP R 220K J 1/10W R331,332 RK73GB2A221J CHIP R 220 J 1/10W R333,334 RK73GB2A224J CHIP R 220K J 1/10W R335,336 RK73GB2A123J CHIP R 12K J 1/10W R337,338 RK73GB2A223J CHIP R 22K J 1/10W R339 RK73GB2A2R2J CHIP R 2.2 J 1/10W R341,342 RK73GB2A123J CHIP R 12K J 1/10W R343,344 RK73GB2A223J CHIP R 22K J 1/10W R345,346 RK73GB2A123J CHIP R 12K J 1/10W R347,348 RK73GB2A223J CHIP R 22K J 1/10W R351,352 RK73GB2A224J CHIP R 220K J 1/10W R353,354 RK73GB2A471J CHIP R 470 J 1/10W R355,356 RK73GB2A224J CHIP R 220K J 1/10W R357,358 RK73GB2A471J CHIP R 470 J 1/10W R361 RK73GB2A152J CHIP R 1.5K J 1/10W R362 RK73GB2A104J CHIP R 100K J 1/10W R363 RK73GB2A101J CHIP R 100 J 1/10W R364 RK73GB2A102J CHIP R 1.0K J 1/10W R371,372 RK73GB2A220J CHIP R 22 J 1/10W R373,374 RK73GB2A102J CHIP R 1.0K J 1/10W R375,376 RK73GB2A220J CHIP R 22 J 1/10W R377,378 RK73GB2A102J CHIP R 1.0K J 1/10W R401 RK73GB2A220J CHIP R 22 J 1/10W R403 RK73GB2A151J CHIP R 150 J 1/10W R405 RK73GB2A151J CHIP R 150 J 1/10W R407 RK73GB2A220J CHIP R 22 J 1/10W R408-410 RK73GB2A181J CHIP R 180 J 1/10W R411,412 RK73GB2A221J CHIP R 220 J 1/10W R413,414 RK73GB2A220J CHIP R 22 J 1/10W R415 RK73GB2A183J CHIP R 18K J 1/10W R416 RK73GB2A101J CHIP R 100 J 1/10W R421,422 RK73GB2A103J CHIP R 10K J 1/10W R423,424 RK73GB2A183J CHIP R 18K J 1/10W R431 RK73GB2A3R3J CHIP R 3.3 J 1/10W R432 RK73GB2A1R0J CHIP R 1.0 J 1/10W R434 RK73GB2A2R2J CHIP R 2.2 J 1/10W R437 RK73GB2A1R0J CHIP R 1.0 J 1/10W R438 RK73GB2A102J CHIP R 1.0K J 1/10W R441,442 RK73GB2A100J CHIP R 10 J 1/10W R502,503 RK73GB2A332J CHIP R 3.3K J 1/10W R504-507 RK73GB2A221J CHIP R 220 J 1/10W R508 RK73GB2A332J CHIP R 3.3K J 1/10W R509 RK73GB2A221J CHIP R 220 J 1/10W R510 RK73GB2A332J CHIP R 3.3K J 1/10W R511 RK73GB2A103J CHIP R 10K J 1/10W R512-517 RK73GB2A220J CHIP R 22 J 1/10W
5 6
