NXR-800
75
PARTS LIST
Ref. No. Ad dress Parts No. Description
Desti-
nation
Ref. No. Ad dress Parts No. Description
Desti-
nation
TX UNIT (X56-3120-14)
Q921 UMG1N TRANSISTOR
Q922 UMG1N TRANSISTOR
Q923 UMG1N TRANSISTOR
Q924 UMG1N TRANSISTOR
Q925 UMG1N TRANSISTOR
Q926 UMG1N TRANSISTOR
Q927 UMG1N TRANSISTOR
Q928 UMG1N TRANSISTOR
Q929 UMG1N TRANSISTOR
Q930 UMG1N TRANSISTOR
Q931 2SC4116(Y)F TRANSISTOR
Q932 2SA1586(Y)F TRANSISTOR
Q960 UMG1N TRANSISTOR
Q961 UMG1N TRANSISTOR
Q962 UMG1N TRANSISTOR
Q963 UMG1N TRANSISTOR
Q964 UMG1N TRANSISTOR
Q965 UMG1N TRANSISTOR
Q966 UMG1N TRANSISTOR
Q967 UMG1N TRANSISTOR
Q968 UMG1N TRANSISTOR
Q969 UMG1N TRANSISTOR
Q970 UMG1N TRANSISTOR
Q971 UMG1N TRANSISTOR
Q972 UMG1N TRANSISTOR
Q973 UMG1N TRANSISTOR
Q974 UMG1N TRANSISTOR
Q975 UMG1N TRANSISTOR
Q976 UMG1N TRANSISTOR
TH101 157-302-65801 THERMISTOR
TH102 157-302-65801 THERMISTOR
