© 2005-10 PRINTED IN JAPAN
B51-8740-00
(
N
)
355
UHF FM TRANSCEIVER
TK-3170
SERVICE MANUAL
GENERAL ................................................... 2
SYSTEM SET-UP ....................................... 2
PARTS LIST ................................................ 3
EXPLODED VIEW..................................... 11
ADJUSTMENT ......................................... 12
CONTENTS
Does not come with antenna.
Antenna is available as an option.
Knob (Selector)
(K29-9340-13)
Knob (Volume)
(K29-9278-13)
Knob (PTT)
(K29-9339-03)
Key top (Side)
(K29-9341-03)
Plastic cabinet assy
(A02-3891-13)
Packing
(G53-1652-11)
This product uses Lead Free solder.
PC BOARD
TX-RX UNIT (X57-7012-72) (A/4)............ 20
TX-RX UNIT (X57-7012-72) (B,C,D/4) ..... 22
SCHEMATIC DIAGRAM........................... 26
BLOCK DIAGRAM .................................... 34
SPECIFICATIONS .................. BACK COVER
SUPPLEMENT
This TK-3170 (E3) service manual con-
tains a number of section which differ
from the service manual (B51-8738-00)
for the TK-3170 (E, X2 versions).
For items other than those in this TK-
3170 (E3) service manual please refer
to the service manual (B51-8738-00)
for the TK-3170 (E, X2 versions).
E3 version
