TM-V708A
2
CIRCUIT DESCRIPTION
Model &
TX-RX UNIT LCD ASSY
Destination
TM-V708A K X57-5860-12 B38-0829-05
Name Parts number Remarks
Destination
K
Modular cable E30-3391-05 3m 1
Panel bracket J29-0663-13 1
J29-0664-13 1
Bracket J29-0628-23 1
Microphone T91-0636-05 DTMF BACK LIT 1
DC cord E30-2111-15 1
Fuse F51-0017-15 15A 1
Mic Hook J19-1526-04 1
Instruction manual B62-1834-00 English 1
Warranty card B46-0469-20 1
Screw set N99-0382-05
For the body and MIC hook
1
Screw set N99-2014-05 For the panel bracket 1
Foot J02-0488-04 For protect from 4
scratch on a desk
Model &
Guarantee frequency range (MHz)
Output Power (W)
Destination
144 440 144 440
TM-V708A K 144-148 438-450 50 35
Outline
This device is a dual-band 144/440MHz FM car transceiver
planned and designed for amateur radio communications and
has the following features.
1. Is capable of receiving packet data on one band while
receiving audio on another band.
2. Enhanced Programmable Memory (PM) channels store
virtually entire current operating environments for your
quick recall.
3. Contains a total of 200 memory channels to program
frequencies and other various data. Allows each memory
channel to be named using up to 8 alphanumeric and
special ASCII characters.
4. "Visual Scan" graphically and simultaneously shows the
conditions of up to 181 frequency channels.
5. Continuous Tone Coded Squelch System (CTCSS) or
Digital Code Squelch (DCS) rejects unwanted calls from
other stations.
6. The separate front panel can be mounted in a convenient
different place from the main unit.
7. Equipped with an easy-to-read large LCD with
alphanumeric display capability.
List of Destination
Accessories
Unit for Model and Destination
