KEP BATCHtrol II - 9 Programming Worksheet

46
Model # _____________________________
Serial # _____________________________
Unit # ______________________________
PRESET _ _ _ _ _ _ _ _
PREWARN _ _ _ _ _ _ _ _
PREset TYPe ■ EZ PRE ■ STD PRE
COUNTer
K-FACTOR _ _ _ _ _ _ _ _
Reset to 0 ■ Set to Preset ■
Decimal Location (0-8)
8 7 6 5 4 3 2 1 0
■ ■ ■ ■ ■ ■ ■ ■ ■ None
RATEmeter
K-FACTOR _ _ _ _ _ _ _ _
WINDOW (02-24) _ _
SIGnifi cant FIGures (1-6) _
WEIGHT (00-99) _ _
Lockout Code
SECUR _ _
CODE _ _ _ _
Output Communication (If applicable)
UNIT (00-15) _ _
Parallel ■ Serial ■
BAUDRATE 300 ■ 2400 ■
600 ■ 4800 ■
1200 ■ 9600 ■
PARITY Space ■ Odd ■
Even ■ Mark ■
Analog Output (If applicable)
Rate ■ Count ■
SET LOW 4 mA= _ _ _ _ _ _ _ _
SET HIGH 20 mA= _ _ _ _ _ _ _ _
9 Programming Worksheet
1 - Not Used
2 - Scaled Pulse Output O.C.
3 - Analog Output
4 - Input A (Pulse/Analog)
5 - Remote Stop/Reset Input
6 - Not Used
7 - Not Used
8 - Not Used
9 - Not Used
10 - Remote Start Input
11 - Ground (-DC), Input Common
12 - Ground (-DC), Input Common
13 - +12 Volts Out
14 - DC Power In (12 - 27 VDC)
15 - Isolate -12 Volts
16 - Isolate +12 Volts
17 - AC In
18 - AC In
19-Prewarn Transistor O.C.
20-Preset Transistor O.C.
R1-N.O
R2-N.C. Preset
R3-Common
R4-N.O
R5-N.C. Prewarn
R6-Common
R3-Common
R2-N.C. Preset
R5-N.C. Prewarn
R2-N.C. Preset
R2-N.C. Preset
R5-N.C. Prewarn
R5-N.C. Prewarn
R2-N.C. Preset
R5-N.C. Prewarn
OUTput FREQuency 20000 ■
2000
■
200
■
10
■
Terminals
