KERN EOB Instruction Manual

KERN
EOB
150K50
EOB
150K50L
EOB
150K50XL
Readability (d) 50 g 50 g 50 g
Weighing range (max) 150 kg 150 kg 150 kg
Reproducibility 50 g 50 g 50 g
Linearity ±100 g ±100 g ±100 g
Recommended
adjustment weight, not
added (class)
100 kg
(M2)
100 kg
(M2)
100 kg
(M2)
Stabilization time (typical) 2.5 sec.
Warm-up time 10 min
Supply voltage 220 V- 240 V, AC 50 Hz
Power pack
secondary voltage
9V, 100 mA
Battery 6 x 1.5 V AA (=9V)
Battery operation period 220 h
Auto-Off 3 min
Weighing Units kg, lb
Ambient temperature
+ 10°C …+ 35°C
Humidity of air max. 80 % (not condensing)
Display unit
(B x D x H) mm
210 x 110 x 45
Cable length display unit 180 cm 270 cm 270 cm
Weighing surface mm 315 x 305 550 x 550 945 x 505
Weight kg (net) 4.2 13.5 19.5
EOB/EOE_L/EOE_XL/EOS-BA-e-1532 5

KERN EOB Specifications

General

Interface	RS-232
Calibration	External calibration
Weighing range [Max]	6 kg
Permissible ambient temperature	5 °C/35 °C
Material	Plastic
Readability	0.1 g
Reproducibility	0.1 g
