KERN EOB Instruction Manual

Plus/minus
weighing
 For example for item weight check, production check etc.
switch-on the balance using ON/OFF button and wait for
zero display.
 Put the nominal weight on the weighing plate and tare to
zero using TARE key. Remove the nominal weight.

 Put the test objects subsequently on the weighing plate, the
respective deviation from the nominal weight is displayed
with the respective sign to „+“ and „-“ (e.g. + 0.037 g).
According to the same procedure also packages with the
same weight can be produced, referring to a nominal
weight.
 Back to weighing mode by pressing the TARE button.
EOB/EOE_L/EOE_XL/EOS-BA-e-1532 22

KERN EOB Specifications

General

Interface	RS-232
Calibration	External calibration
Weighing range [Max]	6 kg
Permissible ambient temperature	5 °C/35 °C
Material	Plastic
Readability	0.1 g
Reproducibility	0.1 g
