770/GS/GJ-BA-defsi-0023 115
6.3 General Specifications
Type of interface Serial point-to-point connector
Operating mode of interface Asynchronous, full-duplex
Standard V28, RS 232 C specification
Handshake*) 2-wire interface: via software (XON/XOFF)
4-wire interface: via hardware handshake lines
with Clear To Send (CTS) and Data Terminal
Ready (DTR)
Transmission rates*) 150, 300, 600, 1.200, 2.400, 4.800, 9.600, 19.200
baud
Character coding 7-bit ASCII
Parity*) Mark**), space**), odd, even
Synchronisation 1 start bit, 1 or 2 stop bits*)
Data output format of the balance*) 16 or 22 characters
Character format*) - 1 start-bit
- 7-bit ASCII
- 1 parity bit
- 1 or 2 stop bits
*) = can be changed by the user
**) = blocked on balances acceptable for legal metrological verification
