770/GS/GJ-BA-defsi-0023 119
Data Output with ID Code
When data with an ID code is output, the ID code consisting of 6 characters precedes
the data with the 16-character format.
During data output, all characters are shifted to the right by 6 places.
1st character 7th 22nd
C C C C C C V * x x x x x x x x * U U U CR LF
* * * * * * * . . . . . . * * *
V = Plus or minus sign
* = Space
x = Digit
U = Unit
. = Decimal point
C = Letter for an ID comment
CR = Carriage Return
LF = Line Feed
When special data codes are output, the letters “Stat“ for status code are assigned to
the 1st through the 4th characters of the data string.
Status-dependent string:
1st character 7th 13th 14th 22nd
S t a t * * * * * * * * A B * * * * * * CR LF
A, B = status codes
Error-dependent string:
1st character 7th 10th - 12th 14th - 16th 22nd
S t a t * * * * * E R R * X Y Z * * * * CR LF
