RIGHT PLACE FOR INSTALLATION

Producthasbeendesignedtobemountedtoworktopsprocuredfrommarket.Asafe

distancemustbeleftbetweentheproductandkitchenwallsorfurniture.Seethedrawing

providedonthenextpageforproperdistances.(valuesinmm).

• Used surfaces, synthetic laminates and adhesives must be heat resistant.

(minimum100°C)

• Kitchencupboardsmustbelevelwithproductandsecured.

• Ifthereisadrawerbelowtheoven,arackmustbeplacedbetweenovenand

drawer.

WARNING:

Donotinstalltheproductnexttorefrigeratorsorcoolers.Theheatemittedbytheproduct

increasestheenergyconsumptionofcoolingdevices.

WARNING:

Donotusedoorand/orhandletocarryormovetheproduct.

45 CM BUILT-IN OVEN INSTALLATION AND MOUNTING

• Place of use for product must be located before starting installation. Product

mustn’tbeinstalledinplaceswhichareundertheeffectofstrongairflow.

• Carrytheproductwithminimumtwopeople.Donotdragtheproductsothatfloor

isn’tdamaged.

• Remove all transportation materials inside and outside the product. Remove

allmaterialsanddocumentsintheproduct.

INSTALLATION UNDER COUNTER

• Cabinmustmatchthedimensionsprovidedinfigure2.

• Aclearancemustbeprovidedattherearpartofthecabinasindicatedinthefigure

sothatnecessaryventilationcanbeachieved.

• After mounting, the clearance between lower and upper part of the counter

isindicatedinfigure5with„A”.It’sforventilationandshouldn’tbecovered.

INSTALLATION IN AN ELEVATED CABINET

• Cabinmustmatchthedimensionsprovidedinfigure4.

• The clearances with the dimensions indicated in the figure must be provided

attherearpartofcabin,upperandlowersectionssothatnecessaryventilation

canbeachieved.
