Kernau KBO 0945 PT B User Manual

EN
71
CLEANING OVEN GLASS
Liftbypressingonplasticlatchesonleftandrightsideasshowninfigure10andpulling
theprofiletowardyourselfasinfigure11.Glassisreleasedafterprofileisremovedas
showninfigure12.Removethereleasedglassbypullingtowardyourselfcarefully.
Outerglassisfixedtoovendoorprofile.Youcanperformglasscleaningeasilyafter
glassesarereleased.Youcanmountglassesbackbyperformingtheoperationsreversely
aftercleaningandmaintenancearecompleted.Ensurethatprofileisseatedproperlyin
place.
CATALYTIC PANEL *
Itislocatedbehindthewireracksoftheoven,attherightandleftwallsofovencavity.
FIGURE 10 FIGURE 11 FIGURE 12
Catalyticpanelremovesoffensiveodourandprovidesusingyourapplianceatitsbest
performance.Overtime,oilandfoododourspermeateintoenamelledovenwallsand
heatingelements.Catalyticpanelabsorbsanyfoodandoilodours,andburnsthemduring
cookingtocleanyouroven.
DETACHING CATALYTIC PANEL
Toremovecatalyticpanel;firstremovethewireracks.Oncewireracksareremoved,
catalytic panel will be free. It is advised to replace the catalytic panel once every
2-3years.
RACK POSITIONS
Itisimportanttoplacethewiregrillintotheovenproperly.Donotallowwirerack
totouchrearwalloftheoven.Rackpositionsareshowninthenextfigure.Youmay
placeadeeptrayorastandardtrayinthelowerandupperwireracks.
Rack4
Rack3
Rack2
Rack1
