Kernau KFC 6008 GE X - Connection to the Flexible Steel Cable; Connection to the Rigid Pipe Installation

EN
55
ConnectorwhichsuppliesthegastothegascookeritisathreadedconnectorG½’’.
   

Incaseofinstallationthegascookeraccordingtotheregulationsforclass2,subclassI,forconnecting
gas cooker to gas installation it is recommended to use only flexible steel cable, corresponding
tonationalregulations.
Theconnectorsuppliesgastothegascookeritisaconnectorwiththread½’’.Itisrecommendedtoseal
theconnectionwithsealingteflontape.Itisrecommendedtouseonlypipesandsealscorresponding
tothecurrentregulations.Themaximumlenghtofflexiblesteelcablecannotexceed2000mm.
Makesureiftheconnectionwillnottouchanyothermovingelements,whichmaycausedamage.

Thecookerisequippedwithspigotwiththread½’’.Itisrecommendedtosealtheconnectionwith
sealingteflontape.Theconnectiontothegasinstallationshouldbeconductedinwaywhichthereisno
tensionsinanypointofinstllation,andonanypartofappliance.Usetheexcessivetighteningtorque
(greaterthan20Nm)orsealingtowcancausejointdamageorleakage.
 
Ifitisnecessarytoreplacethepressurecontrollerduringoperation,thecookermusthaveatechnical
inspectioncoveringgasvalvesandgasoutflowprotection.
Screwed nail
Cylindrical thread
ISO-228-1
WZ plug
Seal
Taper thread
ISO-7-1
Screwed nail
Cylindrical thread
ISO-228-1
Bottom part
of a pipe union
Seal
