2.2 Structure and composition
The system is consists of camera equipment, light source, computers, monitors,
printer. Computer mainframe, display screen and printer are optional
Pic2-1
2.3 Main technical parameters
l Display screen：Resolution is not less than 1024 × 768 pixel.
l Power supply：AC220V±10%，50Hz±2%。
l Input power： the total power is not more than 420VA。
Ø Camera equipment：20VA.
Ø Light source：150VA.
l Fuse specifications, ratings：Light source: F2AL/250V Φ5×20.
l Camera: Horizontal resolution is no less than 480 lines.
l Work distance：200mm～400mm.
l Light source:
Computer mainframe
Display sreen
Printer
C
amera equipment
Stand
Light source
