Chapter III Installation and Connection
3.1 Check up before installation
l Take out the instrument from the box, and lay it in a safe, secure and easy to
observe position, then lock the universal wheel. of the bottom
l Check the random parts in accordance with the packing list to ensure the
integrity of parts.
3.2 Connection
3.2.1 Rockarm assembly
1. Fix the base to the caster bracket according the base notch：
Pic 3-1
2. Insert the strut to the base：
Pic 3-2
Base
caster bracket
strut
