Fasten strain relief for all connection cables - tightening
torque 0.5 Nm.
Fit battery connector onto the battery.
Route the battery cable such that the LEDs are not cov-
ered or trapped.
Fit the housing cover and fasten in place - screw tighten-
ing torque 1.2 Nm.
3
Connection diagram (Mono)
1
2
3 4
L
N
PE
PE N
L I3 - #I1 - I2 - +-
O P Q T UNK L M
D
E F
A
B
C
