Installation and operating manual 47 016-059
4.6 Installing the electrical components
Observe additional instructions and safety information!
▶ The Tronic variants have separate instructions for the control unit.
Fitting the pump(s)
Hang pump(s) in place. ➊
Connect pump(s) to pressure connection. ➋
Lock the quick-release closure in position.
Pull the pump cable through the conduit pipe.
Pull the probe cable / hoses through the conduit pipe if necessary.
L If applicable, ensure that the float switch hangs downwards freely (rest
position).
Fig. [13]
3
2
1
