Installation and operating manual48 016-059
Fitting the level detection (only Tronic variants)
Clip immersion pipe onto fastener (conduit pipe side) if necessary.
Latch securing clip into place.
Fitting the alarm probe (only Tronic variants)
Insert the optical probe into the protective tube and fasten in place with
two screws.
Clip protective tube onto fastener (inlet side). ➍
Latch securing clip into place. ➎
Fig. [14]
3
4
5
1
2
