2.4 PHYSICAL DATA - C36 COMBI & C36P COMBI
Cabinet Height mm 840
Cabinet Width mm 450
Cabinet Depth mm 300
Top Clearance mm 150
Side Clearance mm 5
Base Clearance mm 100
Front Clearance (for servicing) mm 300
Weight - Full kg / (lbs) 50/(110)
Weight - Empty kg / (lbs) 45/(99)
Flow and Return Connection (using pre-installation jig) 22mm Compression
DHW and CWS Connection (using pre-installation jig) 15mm Compression
Gas Connection 15mm Compression
Condensate Connection overflow 22mm plastic
Safety Valve Connection discharge 15mm copper
IP Rating IP20 (IPX0)
Flue and Air Intake Material 50mm muPVC (BS5255 and/or BSEN1566-1 and BSEN1329)
Flue Pipe Size (nominal bore) mm / (in) 50 / (2)
Air Intake Pipe Size (nominal bore) mm / (in) 50 / (2)
Max. Air Intake Length m 39
Max. Flue Outlet Length m 20*
Max. Total Flue Outlet and Air Intake Length m 40
* Flue lengths between 16 and 20m will create a 1% reduction in DHW output.
Flue and Air Intake Material 75mm Keston Composite
Flue Pipe Size (nominal bore) mm / (in) 75 / (3)
Air Intake Pipe Size (nominal bore) mm / (in) 75 / (3)
Max. Air Intake Length m 117
Max. Flue Outlet Length m 60**
Max. Total Flue Outlet and Air Intake Length m 120
** Flue lengths between 48 and 60m will create a 1% reduction in DHW output
2.5 OPTIONAL ACCESSORIES
A range of accessories are available from Keston Boilers Ltd to compliment an installation.
Terminal wall sealing collars are available to make good the external all face whilst working from
the inside of the building using 50mm muPVC (BS5255 and/or BSEN1566-1 and BSEN1329)
pipe. Stand-off frames are available to leave a 50mm gap behind the boiler to allow routing of
pipes behind the boiler.
Description Part Number
Pre-Installation Jig Plate C.10C.0.11.00.0
Flue Terminal Wall Sealing Collar (50mm) C.08.0.00.07.0
Air Terminal Wall Sealing Collar (50mm) C.08.0.00.07.0
50/75mm Flue Adapter C.17.2.00.60.0
Flue Outlet Terminal (75mm) C.17.2.26.00.0
Air Inlet Terminal (75mm) C.17.2.26.00.0
Stand Off Back Plate C.10C.0.01.00.0
Keston Chronotherm Room Controller C.17.4.21.00.0
WD388/0/2004 Chapter 2 : General Instruction The Keston C36 Combi & C36P Combi
Boilers
Installation & Servicing Instructions Page : 6
