7
EN
INDEX
1 Safety warnings p. 8
2 Product overview p. 9
2.1 Product description p. 9
2.2 Models and characteristics p. 9
3 Preliminary checks p. 9
4 Installing the product p. 10
4.1 Installation p. 10
4.2 Installing the rear xing bracket with inward opening p. 10
4.3 Installing the front xing bracket with inward opening p. 10
4.4 Installing the rear xing bracket with outward opening p. 10
4.5 Installing the front xing bracket with outward opening p. 10
4.6 Installing the gear motor p. 11
4.7 Electrical connections p. 11
4.8 Setting of the mechanical limit switch while opening p. 11
4.9 Led replacement - 24 Vdc p. 11
5 Testing and commissioning p. 11
5.1 Testing p. 11
5.2 Commissioning p. 11
6 Images p. 37
7 CE Declaration of Conformity p. 43
