Specifications
Technical:
› Input (Each): 1 HDMI Connector, Type A, 19 Pin Female
› Output (Each): 1 HDMI Connector, Type A, 19 Pin Female; Single CAT5e/6 on RJ45 connectors
› Bandwidth: TMDS bandwidth 3.4 Gb/s
› Control: Front panel push buttons and LEDs; IR sensor front/rear; RS-232 Tx/Rx lines with full
bi-directional operation
› Video/Audio Matrix Switching: Full matrix switching for HDBT/HDMI Video & Audio, DVI Video
› Deep Color Support: Supports digital video formats in Deep Color Mode up to 12 bits/color with
all HDMI and HDCP technologies
› HDMI
®
and HDCP Licensing: Fully licensed and compatible with all HDMI and HDCP technologies
› Link: Single Link
› EDID Control: EDID information is assigned to the inputs from the internal EDID library or from a
display’s internal EDID data
› Lossless Compressed Digital Audio: Dolby
®
TrueHD, Dolby
®
Digital Plus and DTS
™
-HD Master Audio
› DDC Signal (Data): Input DDC Signal - 5 Volts p-p (TTL)
› HDMI Video/Audio Signal: Input Video Signal - 1.2 Volts p-p
› DDC Communication: EDID and HDCP Bi-directional Transparency from Display to Source
› Wired IR: modulated IR signal input, 0-5V TTL or -10to +10V.
› Power: KD-HD4x4/6x6/8x8Lite: +6V/11.6A (70W); KD-CATHD250POHRx:+12V/6A (70W)
General:
› Regulation: CE, RoHS, WEEE
› Rack Mount:
» KD-HD6x6Lite, KD-HD8x8Lite: 2U, Full Rack Width (rack ears included)
» KD-HD4x4Lite: 1U
› Enclosure: Black Metal
› Product Dimensions:
» KD-HD6x6Lite / KD-HD8x8Lite: 17.3” x 6.6” x 3.46”
» KD-HD4x4Lite: 17.125” x 5.50” x 1.75”
› Shipping Dimensions:
» KD-HD6x6Lite / KD-HD8x8Lite: 19.9” x 13.7” x 7.8”
» KD-HD4x4Lite: 21.4” x 9” x 6.9”
› Product Weight:
» KD-HD6x6Lite / KD-HD8X8Lite: 6.6 lb.
» KD-HD4x4Lite: 5.5 lb.
› Shipping Weight:
» KD-HD8X8Lite: 16.5 lb.
» KD-HD6x6Lite: 14.3 lb.
» KD-HD4x4Lite: 12.1 lb.
Important Product Warnings:
1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
7. Only use attachments/accessories specied by the manufacturer.
8. Refer all servicing to qualied service personnel. Servicing is required when the device has
been damaged in any way including:
» Damage to the power supply or power plug
» Exposure to rain or moisture
Power Supply Use:
You MUST use the Power Supply provided with your unit or you VOID the Key Digital
®
Warranty and risk damage to your unit and associated equipment.
