About KD-X222/KD-X222PO
KD-X222/KD-X222PO HDBaseT/HDMI (Tx & Rx) Extenders are an HDCP 2.2 compliant
product that extend 4K/UHD 24/25/30 (4:4:4) and 4K/UHD 60 (4:2:0) signals up to
150 ft. using Key Digital
®
KD-CAT6STP1X Super CAT6A Shielded cable, or up to 125
ft. using a single third-party CAT5e/6 cable. 1080p/60, 1920x1200, 3D signals are
extended up to 250 ft. via single Key Digital
®
KD-CAT6STP1X Super CAT6 shielded
cable, or up to 230 ft. using a single third-party CAT5e/6 cable. In addition to HDMI
video and audio signals, KD-X222/X222PO carries IR or RS-232 for controlling remotely
located equipment or the RS-232 port can be used to control the KD-X222/X222PO.
Key Features
➔
HDBaseT via Single CAT5e/6 UTP/STP Extension:
With fully automatic
adjustment of feedback, equalization, and amplification depending on
cabling length
➔
KD-X222PO:
Features power extension from Tx to Rx with Power Over
HDBaseT, Rx unit does not require power supply
➔
Signal Extension:
» Up to
150 ft. @ 4K
24/25/30(4:4:4)/60(4:2:0) using KD-CAT6STP1X cabling
» Up to
125 ft. @ 4K
24/25/30(4:4:4)/60(4:2:0) using third-party CAT5e/6
UTP/STP cabling
» Up to
250 ft. @ 1080p
/ 1920x1200 using KD-CAT6STP1X cabling
» Up to
230 ft. @ 1080p
/ 1920x1200 using third-party CAT5e/6 UTP/STP
cabling
➔
HDCP 2.2:
Compliancy up to HDCP 2.2 and backward compliant
➔ HDR (High Dynamic Range):
More life-like images through a greater range of
luminance levels
➔
4K/Ultra HD Resolution:
Support for 4096x2160 or 3840x2160 24/25/30Hz at
4:4:4/8 Bit or 60Hz at 4:2:0/8 Bit
➔
Deep Color Support:
Up to UHD/4K 30Hz 4:2:2/12 bits or 60Hz 4:2:0/8 bit
➔ Low Profile:
Super slim chassis design
➔
HDMI
®
and HDCP Licensing:
Fully licensed and compatible with HDCP 2.2 and
HDMI latest technology such as 4K/UHD 4:2:0/8bit at 60f/s
Table of Contents
About KD-X222/KD-X222PO.........................................1
Quick Setup Guide ................................................3
Installation and Operation ...........................................3
Application Examples ..............................................4
Connections .....................................................6
Extending IR or RS-232 Control.......................................8
Settings.........................................................12
LED Indicator Lights ...............................................15
RS-232 Commands ...............................................16
Specifications ....................................................19
Important Product Warnings: .........................................20
Safety Instructions: ................................................20
How to Contact Key Digital®.........................................21
Warranty Information ...............................................21
© 2016 Key Digital, Inc. All rights reserved.
Always follow the instructions provided in this Operating Manual.
Please check the Key Digital Website for the most up-to-date Manual.
