Key-Disp KD718 - Important Information; Operational Warnings; Error Code Definition

Tianjin Key-Disp Technology Co.,Ltd
20
Error Code
Definition
21
Current Abnormality
22
Throttle Abnormality
23
Motor Phase Abnormality
24
Motor Hall Signal Abnormality
25
Brake Abnormality
30
Communication Abnormality
User Manual-KD718
Warnings:
◆Use the display with caution. Don’t attempt to release or link the connector when battery is
on.
◆Try to avoid hitting the display.
◆Don’t modify system parameters to avoid parameter disorder.
◆Make the display repaired when error code appears.
*This manual instruction is a universal version for DISPLAY KD718. Some
versions of this display may be different from specification to specification as to the
software. Please always refer to an actual version.
Attached list 1：Error code definition
