Keyscan NETCOM2 - Specifications and Address Settings; Address Settings

Keyscan Inc. A Member of the Kaba Group
16
Specifications
Input Power Requirements
12VDC, 270mA. Powered by DPS15
Maximum Cable Lengths
ACU/ECU to NETCOM2 Rev. B—22 AWG 5 conductor shielded - max 100 feet /30 m
CIM to NETCOM2 Rev. B—22 AWG 5 conductor shielded - max 49.2 ft/14.9 m @ 9600 bps
Network Communication
Existing LAN or WAN (TCP/IP protocol—port 3001)
Agency Approvals—Ethernet Socket
Complies with Class B limits of EN 55022: 1998 Direct & Indirect ESD.
Complies with EN55024:1998
Dimensions
3.031” x 3.896” (77 mm x 99 mm)
Environmental
Suitable for industrial and commercial applications.
Operating temperatures: 5
0
C to 70
0
C (41
0
F to 158
0
F)
RJ45 Ethernet (Xport) LED States
The RJ45 Ethernet terminal has two bi-colour LEDs:
Link LED (left side)
Activity LED (right side)
Amber – flashing
10 Mbps
Amber – flashing
Half-duplex
Green – flashing
100 Mbps
Green – flashing
Full-duplex
Address Settings
*IP Address:
*Subnet Mask:
Gateway:
**Ethernet Connection
Type:
MAC Address
* Required fields for device configuration with software
** If other than Automatic Negotiation
Keyscan Inc.
901 Burns St., E. Whitby, Ontario, Canada L1N 0E6
1.888.539.7226 (toll free Canada/USA)
905.430.7226 (elsewhere)
www.keyscan.ca
Technical Support
Hours – 9:00 A.M. to 6:30 P.M. Eastern Time
NETCOM2 Rev. B Installation Guide (PC109x – 07.15)
