Keysight Technologies i3070 Series 5i User Manual

8 Replacing the Power Supply
i3070 Inline System (E9988E)
11 Connect a new cable labeled + from F-5 to TB-1.
12 Connect a new cable labeled L4 from F-4 to TB-2.
13 At TB-1, connect a new cable labeled – as shown below:
Continue with Completing the installation.
TB-1
F-5
TB-2
F-4
TB-1
