Source User’s Guide 45
Basic Digital Operation
Licensing
Waveform Licensing Interface
Click file icon in the bottom bar, and click Save key to access the
file type selection menu.
Select Waveform in the left column, and click Recall From File to display files
on the hard disk in C:\NVARB and then, highlight the desired waveform
segment. Press Recall to load this waveform segment from hard disk to ARB
memory.
The selected file name appears in the left column once it is loaded.
Go back to the ARB Setup menu. Click Waveform Utilities, Add Waveform,
select the waveform you want to assign to a slot, and press OK.
Figure 4-2 Assigning the waveform to a slot
