Installation Note N5222-90131 9
Description of the Upgrade
Getting Prepared
Tools Required for the Installation
Description Qty Part Number
T-6 TORX driver - set to 4 in-lbs (0.45 N.m) 1 N/A
T-10 TORX driver - set to 9 in-lbs (1.02 N.m) 1 N/A
T-20 TORX driver - set to 21 in-lbs (2.38 N.m) 1 N/A
5/16-in (8 mm) nutsetter or open end torque wrench - set to 10 in-lbs
(1.13 N.m)
1N/A
5/16-in (8 mm) nutsetter or open end wrench (to stabilize the bias tee
combiner when torquing cables)
1N/A
5/16-in (8 mm) nutsetter or open end torque wrench - set to 21 in-lbs
(2.38 N.m)
1N/A
T-6 TORX driver - set to 6 in-lbs (0.68 N.m) 1 N/A
T-20 TORX driver - set to 21 in-lbs (2.38 N.m) 1 N/A
5/16-in (8 mm) nutsetter or open end torque wrench- set to 8 in-lbs (0.9
N.m)
1N/A
3/16-in (5 mm) nutsetter or open end torque wrench - set to 6 in-lbs
(0.68 N.m)
1N/A
5/8-in (16 mm) nutsetter or open end torque wrench - set to 21 in-lbs
(2.38 N.m)
1N/A
1-in (25.4 mm) torque wrench - set to 72 in-lbs (8.15 N.m) 1 N/A
9 mm nutsetter or open end torque wrench - set to 21 in-lbs (2.38 N.m) 1 N/A
1/4-in (6 mm) open end wrench 1 N/A
Use a 5/16-in torque wrench set to 10 in-lbs on all cable connections,
except the front panel coupler to Bias-T combiner cable connections.
Torque these to 8 in-lbs.
Additional exception: Torque the front and rear panel bulkhead connectors
and these connections to 21 in-lb.
