Page 23Find us at www.keysight.com
PNA Family Network Analyzer Upgrade Kits (continued)
Application options
Upgrade kits are available to add options after initial purchase. To upgrade the PNA-X/PNA/PNA-L, order the corresponding item
number. The model and serial numbers of the instrument to be retrofitted are required as part of the order.
Description Required Option
For PNA-X
Series
For PNA
Series
For PNA-L
Series
User
Installable
Pulse, antenna, mm-wave
Pulsed-RF measurements Option 025
1
N524xAU-008 N522xAU-008 n/a Yes
Add IF inputs N524xAU-020 N522xAU-020 n/a Yes
Add pulse modulator to internal 1st source N524xAU-021 N522xAU-021 n/a Yes
Add pulse modulator to internal 2nd source Option 224, 400, 401, 417, 419, or 423 N524xAU-022 N522xAU-022 n/a Yes
Add four internal pulse generators N524xAU-025 N522xAU-025 n/a Yes
Fast CW sweep N524xAU-118 N522xAU-118 n/a Yes
Nonlinear vector network analysis
Nonlinear component characterization Options 419 and 080, or 400, H85 and 080 N524xAU-510
2
n/a n/a Yes
Nonlinear component characterization Export-control version. Option 419 and 080, or
400, H85, and 080
N524xAU-511
2
n/a n/a Yes
Nonlinear X-parameters Options 423 and 510 or 511 N524xAU-514
3
n/a n/a Yes
Nonlinear pulse envelope domain Requries Options 021, 025 and either one of
510 or 511
N524xAU-518 n/a n/a Yes
Arbitrary load-impedance X-parameters Option 514 N524xAU-520 n/a n/a Yes
Arbitrary load control X-parameters Requires Option 520 and Windows 7 N524xAU-521 n/a n/a Yes
Arbitrary load-control device characterization Requires Option 510 or 511 and Windows 7 N524xAU-522 n/a n/a Yes
Calibration software
Perpetual license for built-in performance test software
for Keysight inclusive calibration
N524xAU-897 N522xAU-897 N523xAU-897 Yes
Perpetual license for built-in performance test
software for standard compliant calibration
N524xAU-898 N522xAU-898 N523xAU-898 Yes
1. For measuring frequency converters, Option 082 or 083 is required.
2. Pulse capability requires option 021 and 025
3. Pulse capability requires option 021, 022 and 025
