For devices with 3.5 mm or SMA connectors
Mechanical calibration kits
85052B standard: DC to 26.5 GHz. Includes:
– 00902-60003 3.5 mm (m) fixed load
– 00902-60004 3.5 mm (f) fixed load
– 00911-60019 3.5 mm (m) sliding load
– 00911-60020 3.5 mm (f) sliding load
– 85052-60006 3.5 mm (m) short
– 85052-60007 3.5 mm (f) short
– 85052-60008 3.5 mm (m) open
– 85052-60009 3.5 mm (f) open
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85052C precision TRL: DC to 26.5 GHz. Includes:
– 00902-60003 3.5 mm (m) fixed load
– 00902-60004 3.5 mm (f) fixed load
– 85052-60006 3.5 mm (m) short
– 85052-60007 3.5 mm (f) short
– 85052-60008 3.5 mm (m) open
– 85052-60009 3.5 mm (f) open
– 85052-60032 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60033 3.5 mm (m) to 3.5 mm (m) adapter
– 85052-60034 3.5 mm (f) to 3.5 mm (m) adapter
– 85052-60035 3.5 mm short TRL line
– 85052-60036 3.5 mm long TRL line
85052D economy: DC to 26.5 GHz. Includes:
– 00902-60003 3.5 mm (m) fixed load
– 00902-60004 3.5 mm (f) fixed load
– 85052-60006 3.5 mm (m) short
– 85052-60007 3.5 mm (f) short
– 85052-60008 3.5 mm (m) open
– 85052-60009 3.5 mm (f) open
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60013 3.5 mm (f) to 3.5 mm (m) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
Electronic calibration kits
85093C RF ECal: 300 kHz to 9 GHz, 2-ports; Standard module
includes:
– Option M0F with: 85093-60008 3.5 mm (f) to 3.5 mm (m)
ECal module
– Option 00F module with: 85093-60010 3.5 mm (f) to
3.5 mm (f) ECal module
– Option 00M module with: 85093-60009 3.5 mm (m) to
3.5 mm (m) ECal module
– Option 00A adds:
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
85093C-xxx mixed-connector options:
Port A option Port B option
Type (f) (m) Type (f) (m) Type (f) (m)
3.5 mm 101 102 Type-N
50 ohm
203 204 7-16 205 206
N4431B Microwave ECal: 300 kHz to 13.5 GHz, 4-ports
Includes: Option 010 module with:
N4431-60006 4 x 3.5 mm (f) ECal module
N4431B-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
Type-N 50 ohm (f) 103 203 303 403
Type-N 50 ohm (m) 104 204 304 404
7-16 (f) 105 205 305 405
7-16 (m) 106 206 306 406
N4433A Microwave ECal: 300 kHz to 20 GHz, 4-ports.
Includes: Option 010 module with:
N4433-60003 4 x 3.5 mm (f) ECal module
N4433A-xxx mixed-connector options:
Connector type Port A
option
Port B
option
Port C
option
Port D
option
3.5 mm (f) 101 201 301 401
3.5 mm (m) 102 202 302 402
N4691B Microwave ECal: 300 kHz to 26.5 GHz, 2-ports.
Includes:
– Option M0F module with:
N4691-60004 3.5 mm (f) to 3.5 mm (m) ECal module
– Option 00M module with:
N4691-60005 3.5 mm (m) to 3.5 mm (m) ECal module
– Option 00F module with:
N4691-60006 3.5 mm (f) to 3.5 mm (f) ECal module
– Option 00A adds:
– 85052-60012 3.5 mm (f) to 3.5 mm (f) adapter
– 85052-60014 3.5 mm (m) to 3.5 mm (m) adapter
