Keysight Technologies U2000 Series User Manual

3 Specifications and Characteristics
66 U2000 Series Operating and Service Guide
Normal Mode Key Specifications and Characteristics
Parameters
1
1 Not applicable for U2004A
Performance
Maximum video bandwidth 40 kHz
Minimum rise time 40 µs
Minimum fall time 40 µs
Range settling time 150 µs
Minimum pulse width 200 µs
Sampling rate 1.47 Msps
Maximum capture length 150 ms
Maximum pulse repetition rate 150 kHz
Dynamic range U2000/1/2A: –30 dBm to +20 dBm
U2000/1/2H: –20 dBm to +30 dBm
U2000/1B: 0 dBm to +44 dBm
