Keysight Technologies U2000 Series - Table 4-6 Power Sensor SWR and Reflection Coefficient for the U2001 H; Table 4-7 Power Sensor SWR and Reflection Coefficient for the U2002 H; Table 4-8 Power Sensor SWR and Reflection Coefficient for the U2000 B; Table 4-9 Power Sensor SWR and Reflection Coefficient for the U2001 B

Service 4
U2000 Series Operating and Service Guide 73
Tab le 4- 6 Power Sensor SWR and Reflection Coefficient for the U2001H
Tab le 4- 7 Power Sensor SWR and Reflection Coefficient for the U2002H
Tab le 4- 8 Power Sensor SWR and Reflection Coefficient for the U2000B
Tab le 4- 9 Power Sensor SWR and Reflection Coefficient for the U2001B
Frequency Actual
Measurement
Maximum
Rho
SWR
10 MHz to 6 GHz 0.070 1.15
Frequency Actual
Measurement
Maximum
Rho
SWR
50 MHz to 8 GHz 0.070 1.15
8 GHz to 12.4 GHz 0.111 1.25
12.4 GHz to 18 GHz 0.123 1.28
18 GHz to 24 GHz 0.130 1.30
Frequency Actual
Measurement
Maximum
Rho
SWR
10 MHz to 2 GHz 0.057 1.12
2 GHz to 12.4 GHz 0.078 1.17
12.4 GHz to 18 GHz 0.107 1.24
Frequency Actual
Measurement
Maximum
Rho
SWR
10 MHz to 2 GHz 0.057 1.12
2 GHz to 6 GHz 0.078 1.17
