42 Chapter 8
Scale Fidelity
Figure 8-1 Scale Fidelity Setup
NOTE Averaging is used for all measurements to improve repeatability and reduce
measurement uncertainty.
Cable, BNC 120 cm Frequency: 10 MHz 10503A
Synthesized Sweeper Output Level Accuracy: 0 to –15 dBm: ±1.0 dB
at 50 MHz
PSG
a. for Options 503, 508, 513, 526
b. for Options 543, 544, 550
Item
Critical Specifications
(for this test)
Recommended
Keysight Model
To Next Page
