Keysight X-Series Signal Analyzers
PXA N9030A
Functional Tests
6 Frequency Response (Flatness)
Test Limits
The frequency response test measures the signal analyzer’s amplitude error as
a function of the tuned frequency. Measurements are made ranging from 50
MHz to the maximum frequency range of your analyzer. The signal source
amplitude is measured with a power meter to eliminate error due to source
flatness. The measured value is normalized to 50 MHz.
Frequency Range Limit Relative to 50 MHz
20 Hz to 3.6 GHz ±1.5 dΒ
> 3.6 GHz to 8.4 GHz ±2.5 dΒ
> 8.4 GHz to 13.6 GHz ±3.0 dΒ
> 13.6 GHz to 26.5 GHz ±3.5 dΒ
> 26.5 GHz to 34.5 GHz ±3.5 dΒ
> 34.5 GHz to 50 GHz ±4.2 dΒ
Item
Critical Specifications
(for this test)
Recommended
Keysight Model
Adapter, Type N (m) to 3.5 mm
(m)
a
Frequency: 10 MHz to 18 GHz
VSWR: < 1.1:1
1250-1743
Adapter, 3.5 mm (f) to 3.5 mm
(f)
a
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.1:1
83059B
Cable, 3.5 mm, 1 meter
a
(Opt 503, 508, 513, 526)
Frequency: 10 MHz to 26.5 GHz
VSWR: < 1.4:1
11500E
Cable, 2.4 mm, 1 meter
b
(Opt 543, 544, 550)
Frequency: 10 MHz to 50 GHz
VSWR: < 1.55:1
8120-6164
