Keysight E5061B Configuration Guide

Page 12
Find us at www.keysight.com
Calibration kits (for 75 Ω system)
Model No. Description
Type-N
Mechanical calibration kits
85036B 75 Ω standard calibration kit, DC to 3 GHz. Includes;
- Type-N (m) broadband load
- Type-N (f) broadband load
- Type-N (m) short
- Type-N (f) short
- Type-N (m) open
- Type-N (f) open body
- Type-N (f) open center conductor extender
- Type-N (m) to type-N (m) adapter
- Type-N (f) to type-N (f) adapter
- Type-N (m) to type-N (f) adapter
85036E 75 Ω economy calibration kit, DC to 3 GHz. Includes;
- Type-N (m) broadband load
- Type-N (m) combined Open/Short
Electronic calibration kits
85096C
1
RF ECal module
2-port (75 Ω type-N), 300 kHz to 3 GHz. The sexes of the connectors depend on the option.
85096C-M0F Type-N (m) to Type-N (f) RF ECal module
85096C-00F Type-N (f) to Type-N (f) RF ECal module
85096C-00M Type-N (m) to Type-N (m) RF ECal module
85096C-00A Adds;
- Type-N (f) to Type-N (f) adapter
- Type-N (m) to Type-N (m) adapter
Test accessories (for 75 Ω system)
Model No. Description
Test Port Cable
11857B 75 Ω type-N cable set, 61 cm (24 in). Includes;
- Type-N (m) to type-N (m) cable
- Type-N (m) to type-N (f) cable
11857F 75 Ω type-N to type-F cable set, 61 cm (24 in)
11857F-M0F Includes;
- Type-N (m) to type-F (m) cable
- Type-N (m) to type-F (f) cable
11857F-00F Includes;
- Type-N (m) to type-F (f) cable
11857F-00M Includes;
- Type-N (m) to type-F (m) cable
11857-60005 Precision 75 Ω Type-N cable, 61 cm (24 in) cable with male connectors.
Minimum Loss Pad
11852B Type-N minimum loss pad. DC to 3 GHz,
50 Ω type-N (f) to 75 Ω type-N (m)
11852B-004 50 Ω type-N (m) to 75 Ω type-N (f)
1. This ECal module cannot be used in the low frequency range below 300 kHz.
