Keysight E5061B Configuration Guide

Page 11
Find us at www.keysight.com
Calibration kits (for 50 Ω system, continued)
Model No. Description
7-16
Mechanical calibration kits
85038A 50 Ω standard calibration kit, DC to 7.5 GHz. Includes;
- 7-16 (m) Load / 7-16 (m) Open / 7-16 (m) Short
- 7-16 (f) Load / 7-16 (f) Open / 7-16 (f) Short
- Torque wrench
- Open-end wrench
85038F 50 Ω standard calibration kit, DC to 7.5 GHz. Includes;
- 7-16 (f) Load / 7-16 (f) Open / 7-16 (f) Short
- 7-16 (f) to 7-16 (f) adapter
85038M 50 Ω standard calibration kit, DC to 7.5 GHz. Includes;
- 7-16 (m) Load / 7-16 (m) Open / 7-16 (m) Short
- 7-16 (m) to 7-16 (m) adapter
Electronic calibration kits
85098C
1
RF ECal module
2-port (7-16), 300 KHz to 7.5 GHz. The sexes of the connectors depend on the option.
85098C-M0F
2
7-16 (m) to 7-16 (f) RF ECal module
85098C-00F
2
7-16 (f) to 7-16 (f) RF ECal module
85098C-00M
2
7-16 (m) to 7-16 (m) RF ECal module
85098C-00A Adds;
- 7-16 (m) to 7-16 (m) adapter
- 7-16 (f) to 7-16 (m) adapter
7mm
Mechanical calibration kits
85031B 50 Ω economy calibration kit, DC to 6 GHz. Includes;
- 7 mm Load (2 qty.)
- 7 mm combined Open/Short
1. This ECal module cannot be used in the low frequency range below 300 kHz.
2. Mixed connector options are also available. Visit our website for more details about the ECal: www.keysight.com/find/ecal
