Keysight E5061B Configuration Guide

Page 10
Find us at www.keysight.com
Calibration kits (for 50 Ω system, continued)
Model No. Description
3.5mm
Mechanical calibration kits
85033E 50 Ω standard calibration kit, DC to 9 GHz. Includes;
- 3.5 mm (m) Load / 3.5 mm (m) Open / 3.5 mm (m) Short
- 3.5 mm (f) Load / 3.5 mm (f) Open / 3.5 mm (f) Short
- Torque wrench
85033E-100 Adds 3.5mm (f) to 3.5 mm (f) adapter
85033E-200 Adds 3.5mm (m) to 3.5 mm (m) adapter
85033E-300 Adds 3.5mm (f) to 3.5 mm (m) adapter
85033E-400 Adds;
- 3.5 mm (m) to 50 Ω type- N (m) adapter
- 3.5 mm (f) to 50 Ω type- N (f) adapter
- 3.5 mm (f) to 50 Ω type- N (m) adapter
- 3.5 mm (m) to 50 Ω type- N (f) adapter
85033E-500 Adds;
- 3.5 mm (m) to 7 mm adapter (2 qty.)
- 3.5 mm (f) to 7 mm adapter (2 qty.)
Electronic calibration kits
85093C
1
RF ECal module
2-port (3.5 mm), 300 kHz to 9 GHz
85093C-M0F
2
3.5 mm (f) to 3.5 mm (m) RF ECal module
85093C-00M
2
3.5 mm (m) to 3.5 mm (m) RF ECal module
85093C-00F
2
3.5 mm (f) to 3.5 mm (f) RF ECal module
85093C-00A Adds;
- 3.5 mm (f) to 3.5 mm (f) adapter
- 3.5 mm (m) to 3.5 mm (m) adapter
N7550A
3
Economy ECal module, DC to 4 GHz, 2-port
N7551A
3
Economy ECal module, DC to 6.5 GHz, 2-port
N7552A
3
Economy ECal module, DC to 9 GHz, 2-port
N7553A
3
Economy ECal module, DC to 14 GHz, 2-port
N7554A
3
Economy ECal module, DC to 18 GHz, 2-port
N7555A
3
Economy ECal module, DC to 26.5 GHz, 2-port
N755xA-3MF 3.5 mm (m) to 3.5 mm (f) ECal module
N755xA-3MM 3.5 mm (m) to 3.5 mm (m) ECal module
N755xA-3FF 3.5 mm (f) to 3.5 mm (f) ECal module
Selectable connector type
Electronic calibration kit
N4431B
1
RF ECal module
4-port, 9 kHz to 13.5 GHz. The connector type depends on the option.
N4431B-010
2
Four 3.5 mm (f) connectors
N4431B-020
2
Four 50 Ωtype-N (f) connectors
1. These ECal modules cannot be used in the low frequency range below 300 kHz or 9 kHz.
2. Mixed connector options are also available. Visit our website for more details about the ECal: www.keysight.com/find/ecal
3. The E5061B must have firmware revision B.04.86 or above for the operation with the N755xA series ECal module.
