Calibration kits (for 50 Ω system)
Model No. Description
Type-N
Mechanical calibration kits
85032E 50 Ω economy calibration kit, DC to 6 GHz. Includes;
- Type-N (m) fixed load
- Type-N (m) combined open/short
85032F 50 Ω standard calibration kit, DC to 9 GHz. Includes;
- Type-N (m) fixed load
- Type-N (f) fixed load
- Type-N (m) Open
- Type-N (f) Open
- Type-N (m) Short
- Type-N (f) Short
85032F-100 Adds 50 Ω type-N (f) to type-N (f) adapter
85032F-200 Adds 50 Ω type-N (m) to type-N (m) adapter
85032F-300 Adds 50 Ω type-N (m) to type-N (f) adapter
85032F-500 Adds;
- 50 Ω type-N (m) to 7 mm adapter (2 qty.)
- 50 Ω type-N (f) to 7 mm adapter (2 qty.)
Electronic calibration kits
85092C
1
RF ECal module
2-port (50 Ω type-N), 300 kHz to 9 GHz. The sexes of the connectors depend on the option.
85092C-M0F
2
Type-N (f) to Type-N (m) RF ECal module
85092C-00M
2
Type-N (m) to Type-N (m) RF ECal module
85092C-00F
2
Type-N (f) to Type-N (f) RF ECal module
85092C-00A Adds;
- Type-N (f) to Type-N (f) adapter
- Type-N (m) to Type-N (m) adapter
Electronic calibration (ECal) modules
85092C RF ECal module
2-port (50 Ω type-N), 300 kHz to 9 GHz. The sexes of the connectors depend on the option.
N7550A
3
Economy ECal module, DC to 4 GHz, 2-port
N7551A
3
Economy ECal module, DC to 6.5 GHz, 2-port
N7552A
3
Economy ECal module, DC to 9 GHz, 2-port
N7553A
3
Economy ECal module, DC to 14 GHz, 2-port
N7554A
3
Economy ECal module, DC to 18 GHz, 2-port
N755xA-NMF Type-N (m) to Type-N (f) ECal module
N755xA-NMM Type-N (m) to Type-N (m) ECal module
N755xA-NFF Type-N (f) to Type-N (f) ECal module
1. This ECal module cannot be used in the low frequency range below 300 kHz.
2. Mixed connector options are also available. Visit our website for more details about the ECal: www.keysight.com/find/ecal
3. The E5061B must have firmware revision B.04.86 or above for the operation with the N755xA series ECal module.
