Keysight E5063A Configuration Guide

02 | Keysight | E5063A ENA Series Network Analyzer - Configuration Guide
Ordering Guide
The following steps will guide you through configuring your Keysight Technologies’ E5063A.
Standard furnished item
Description Additional information
Installation guide Contains the information necessary to start up with the E5063A.
CD ROM IO libraries
Power Cable
Calibration of Certification
Step 1. Choose frequency option (must choose one of the eight frequency options.)
Description Option no.
Network Analyzer 100 kHz to 500 MHz, S-parameter test set, 50 Ω system impedance E5063A-205
Network Analyzer 100 kHz to 1.5 GHz, S-parameter test set, 50 Ω system impedance E5063A-215
Network Analyzer 100 kHz to 3 GHz, S-parameter test set, 50 Ω system impedance E5063A-235
Network Analyzer 100 kHz to 4.5 GHz, S-parameter test set, 50 Ω system impedance E5063A-245
Network Analyzer 100 kHz to 6.5 GHz, S-parameter test set, 50 Ω system impedance E5063A-265
Network Analyzer 100 kHz to 8.5 GHz, S-parameter test set, 50 Ω system impedance E5063A-285
Network Analyzer 100 kHz to 14 GHz, S-parameter test set, 50 Ω system impedance E5063A-2D5
Network Analyzer 100 kHz to 18 GHz, S-parameter test set, 50 Ω system impedance E5063A-2H5
Step 2. Choose software option (If not required, go to step 4.)
Description Option no. Requires Not compatible Additional information
Time Domain/Test wizard E5063A-011 None None
1
This option is required for time domain analysis or PCB
measurements
Time Domain E5063A-010 None E5063A-011 Adds time domain transform and gating capabilities
Wireless power transfer
analysis
E5063A-006 None None This option is required for wireless power transfer efficiency test of
wireless power transfer modules
1. E5063A-011 is a superset of E5063A-010. E5063A-011 includes the capability of E5063A-010.
Step 3. Choose hardware option
Description Option no. Requires Not compatible Additional information
Add GPIB interface E5063A-721 None E5063A-722 Must choose either Option 721 or 722
Without GPIB interface E5063A-722 None E5063A-721 Must choose either Option 721 or 722
Add handler I/O interface E5063A-731 None E5063A-732 Must choose either Option 731 or 732
Without handler I/O interface E5063A-732 None E5063A-731 Must choose either Option 731 or 732
Step 4. Choose storage drive option (mandatory option)
Description Option no. Requires Not compatible Additional information
Standard storage drive E5063A-019 None None Option 019 is the only storage drive option for the E5063A.
Must choose this option
