1-16 Electronic Calibration Modules Reference Guide
General Information
Models and Options
1-
Table 1-5 N4432D and N4433D Modules (All connectors are female)
Model
Number
Connector Type Port A, B, C, D
a
Operating Frequency Option
N4433D 3.5 mm -f- DC to 26.5 GHz (0DC) 010
300 kHz to 26.5 GHz (003)
N4432D Type-N 50Ω -f- DC to 18 GHz (0DC) 020
300 kHz to 18 GHz (003)
a. Option 0DC frequency range is DC to xx.x GHz. Option 003 frequency range is 300 kHz to xx.x GHz.
Table 1-6 N4432D Mixed Connector Options
Connector Type Port A Option Port B Option Port C Option Port D Option
3.5 mm -f-
a
101 201 301 401
3.5 mm -m-
a
102 202 302 402
Type-N 50Ω -f- 103 203 303 403
Type-N 50Ω -m- 104 204 304 404
a. Frequency range of ECal module limited by other connectors.
Table 1-7 N4433D Mixed Connector Options
Connector Type Port A Option Port B Option Port C Option Port D Option
3.5 mm -f- 101 201 301 401
3.5 mm -m- 102 202 302 402
Other
N4432/3D
Options
Description
A6J Adds ANSI Z540-1-1994 Calibration
1A7 Calibration + Uncertainties + Guardbanding
UK6 Adds commercial calibration certificate with measured data.
