Calibration 3
Model N6705 Service Guide 63
Step 6.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. If
calibration is complete, select Close.
CAL:DATA <data>
Steps 7 and 8 only apply to model N6784A.
Step 7.
Select the third voltage calibration point for the negative range.
Front Panel:
SCPI Command:
The third calibration point is automatically
selected. “Enter P3 measured data” should
be displayed.
CAL:LEV P3
*OPC?
Step 8.
Measure the output voltage with the DMM and enter the data. The value
should be negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Low Range Voltage Programming - Models N6781A, N6782A,
N6784A
Step 1.
Select the low-voltage programming range. The value entered must be
the maximum voltage of the range to be calibrated. This example selects
the 6 V range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu, select Voltage,
Low Range Programming. Then select Start.
CAL:VOLT 6, (@1)
Step 2.
Select the first voltage calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should
be displayed.
CAL:LEV P1
*OPC?
Step 3.
Measure the output voltage with the DMM and enter the data. This value
may be positive or negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
