3 Calibration
64 Model N6705 Service Guide
Step 4.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should
be displayed.
CAL:LEV P2
*OPC?
Step 5.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. If
calibration is complete, select Close.
CAL:DATA <data>
Step 6 only applies to models N6781A and N6782A.
Step 6.
Repeat steps 1 through 5 for the 600 mV range.
Steps 7 through 9 only apply to model N6784A.
Step 7.
Select the third voltage calibration point for the negative range.
Front Panel:
SCPI Command:
The third calibration point is automatically
selected. “Enter P3 measured data” should
be displayed.
CAL:LEV P3
*OPC?
Step 8.
Measure the output voltage with the DMM and enter the data. The value
should be negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close
CAL:DATA <data>
Step 9.
Repeat steps 1 through 5, 7 and 8 for the 600 mV range.
Low Range Voltage Measurement - Models N6781A, N6782A,
N6784A
Step 1.
Select the low-voltage measurement range. The value entered must be
the maximum voltage of the range to be calibrated. This example selects
the 1 V range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu, select
Voltage, Low Range Measurement. Then
select Start.
CAL:VOLT:MEAS 1, (@1)
Step 2.
Select the first voltage calibration point.
