Calibration 3
Model N6705 Service Guide 65
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 3.
Measure the output voltage with the DMM and enter the data. This value
may be positive or negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 4.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should be
displayed.
CAL:LEV P2
*OPC?
Step 5.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Step 6 only applies to models N6781A and N6782A.
Step 6.
Repeat steps 1 through 5 for the 100 mV range.
Steps 7 through 9 only apply to model N6784A.
Step 7.
Select the third voltage calibration point for the negative range.
Front Panel:
SCPI Command:
The third calibration point is automatically
selected. “Enter P3 measured data” should be
displayed.
CAL:LEV P3
*OPC?
Step 8.
Measure the output voltage with the DMM and enter the data. The value
should be negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into the
data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Step 9.
Repeat steps 1 through 5, 7 and 8 for the 100 mV range.
