3 Calibration
66 Model N6705 Service Guide
Positive Voltage Limit - Models N6781A, N6782A, N6784A
Step 1.
Select the positive voltage limit range. The value to program a range
must be the maximum voltage of the range to be calibrated. This
example selects the 20 V positive limit range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu,
select Voltage, Positive Voltage
Limit. Then select Start. Select
the 20 V range.
CAL:VOLT:LIM:POS 20, (@1)
Step 2.
Select the first voltage calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 3.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 4.
Select the second voltage calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should be
displayed.
CAL:LEV P2
*OPC?
Step 5.
Measure the output voltage with the DMM and enter the data.
Front Panel:
SCPI Command:
Enter the value from the external DMM into the
data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Step 6.
Repeat steps 1 through 5 for the 6 V positive limit range.
