3 Calibration
70 Model N6705 Service Guide
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should be
displayed.
CAL:LEV P2
*OPC?
Step 6.
Measure the current with the
Keysight 3458A and enter the value.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 7.
Select the third current calibration point for the negative range.
Front Panel:
SCPI Command:
The third calibration point is automatically
selected. “Enter P3 measured data” should be
displayed.
CAL:LEV P3
*OPC?
Step 8.
Measure the current with the Keysight 3458A and enter the value. This
value should be negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
Step 9.
Repeat steps 1 through 8 for the 10 mA programming range of model
N6784A.
100 mA Measurement Range - All Models
Step 1.
Connect only the current measurement terminals of the Keysight 3458A
to the output terminals (see Cal Setup D without the resistor).
Step 2.
Select the 100 mA range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu, select
Current, 100 mA Measurement
Range. Then select Start.
CAL:CURR:MEAS 0.1, (@1)
Step 3.
Select the first current calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 4.
Measure the current with the
Keysight 3458A and enter the value.
