Calibration 3
Model N6705 Service Guide 71
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 5.
Select the second current calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should be
displayed.
CAL:LEV P2
*OPC?
Step 6.
Measure the current with the Keysight 3458A and enter the value. This
value should be negative.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next. When
calibration is complete, select Close.
CAL:DATA <data>
1 mA Measurement Range - All Models
Step 1.
Connect the Keysight 3458A in series with a 10 kΩ resistor to the output
(see equipment list in chapter 2 and Cal Setup D).
Step 2.
Select the 1 mA range of output 1.
Front Panel:
SCPI Command:
From the Calibration menu, select Current,
I mA Measurement Range. Select Start.
CAL:CURR:MEAS
0.001, (@1)
Step 3.
Select the first current calibration point.
Front Panel:
SCPI Command:
The first calibration point is automatically
selected. “Enter P1 measured data” should be
displayed.
CAL:LEV P1
*OPC?
Step 4.
Measure the current with the Keysight 3458A and enter the value.
Front Panel:
SCPI Command:
Enter the value from the external DMM into
the data field and then select Next.
CAL:DATA <data>
Step 5.
Select the second current calibration point.
Front Panel:
SCPI Command:
The second calibration point is automatically
selected. “Enter P2 measured data” should be
displayed.
CAL:LEV P2
*OPC?
Step 6.
Measure the current with the Keysight 3458A and enter the value. This
value should be negative.
