29 | Keysight | N9038A MXE EMI Receiver Self-Guided Demonstration - Demo Guide
File structures and locations
The MXE can save measurement results and instrument configurations. Table 4 lists the
kinds of files supported on the MXE, including settings, screenshots, and measurement
results.
There are two locations to store both limit lines and amplitude correction data,
named “Preloaded” and “User.” Keysight Technologies, Inc. uses the preloaded folder
to store factory-configured limit and correction files. The contents of these files can
be overwritten when the instrument software is updated. The user folder is designed
specifically for customer use. Information in the user folders is not over-written during
software updates.
The default folder selection for recalling limit lines and amplitude correction data can be
selected using the following paths:
[Recall], {Data}, {Limit}, {Limit}, {Preloaded Limits} or {Limit (User)}
[Recall], {Data}, {Amplitude Correction}, {Amplitude Correction}, {Preloaded Corrections}
or {Correction (User)}
Table 4. File types and directory path
File Category File Type Directory Path
State file .state \\My Documents\EMI\state
State can also be saved into registers by pushing [Save], {State}, {Register 1},…
{Register 16}
Screen image .png \\My Documents\EMI\screen
Amplitude corrections (Preloaded)
If {Preloaded Corrections} is selected
.csv \\My Documents\EMC Limits and Ampcor\Ampcor
Amplitude corrections (User)
If {Correction (User)} is selected
.csv \\My Documents\amplitudeCorrections
Limit lines (Preloaded) If {Preloaded Limits} is
selected
.csv \\My Documents\EMC Limits and Ampcor\Limits
Limit lines (User)
If {Limit (User)} is selected
.csv \\My Documents\EMI\data\FSCan\Limits
Trace data .csv \\My Documents\EMI\data\FSCan\Traces
Signal list .csv \\My Documents\EMI\data\FSCan\SignalList
Scan table .csv \\My Documents\EMI\data\FSCan\ScanTable
Measurement results (report) .html, .pdf \\My Documents\EMI\data\FSCan\MeasResult
Web Resources
Product page: www.keysight.com/find/MXE
X-Series signal analyzers: www.keysight.com/find/X-Series
X-Series measurement applications: www.keysight.com/find/X-Series_Apps
