05 | Keysight | N9038A MXE EMI Receiver Self-Guided Demonstration - Demo Guide
Equipment Requirements
N9038A MXE EMI receiver Firmware A.13.58 or above
N5181/ 2B MXG X-Series signal generator Pulse signal
A whip antenna Any whip antenna working at up to 3 GHz
Demonstration Preparation
This demonstration guide includes the following sections:
– Making measurements
– Diagnostic testing tools
– Single frequency measurement
– Other features
The Making Measurements section is organized according to the test flow recommended
by CISPR as shown in Figure 2. The demonstrations are designed to be replicated
sequentially.
For most of the demonstrations, test signals were received by a whip antenna, such as
FM radio and cellular signals. The MXG was only used to generate a pulse signal for the
APD demo. All keystrokes surrounded by [ ] indicate front panel hard keys and keystrokes
surrounded by { } indicate soft keys on the side of display.
All of these demonstrations use commercial EMI settings. If you wish to use MIL-
STD-461 settings for these demonstrations, make the corresponding setting changes
indicated in each demonstration.
